GPS to CAN BUS
J1939 to 802.15.1 (BT)
Overview
The GPS to CAN Bus device is a compact and efficient solution for integrating GPS data into multiple vehicle and industrial communication networks. It supports seamless data transfer to CAN, CAN-FD, J1939, and also works with NMEA2000 and CANopen protocols for broad compatibility.
With versatile connectivity options like RS-232, RS-485, USB, and 802.15.1 (Bluetooth), this module ensures fast and reliable performance in diverse environments. It is ideal for automotive, marine, and industrial applications that require accurate and real-time GPS data communication.
Buy NowPower Savings
The GPS to CAN Bus device is designed to prevent vehicle battery drain by automatically entering deep sleep mode when not in use.
Binary Boost TM
Binary Boost TM is a simple and efficient technology for doubling the bandwidth between the host and VNA-SA.
Features:
- J1587/J1708 x1, with 5.2.2.1 compliance
- J1939/CAN x2, with auto baud (250K and 500K)
- RS-232, from 9.6Kbps to 1Mbps
- Internal message buffering
- 200 message filters or pass-all mode
- Collision detection, with automatic retries
- Field programmable
- SAE J1939-82 certified
- Automatic deep sleep mode (< 1mA)
- Load dump and reverse bias protection
